Cooling Process Optimization Through a Three-Phases Thermo-Hydraulic Model

COMSOL European Conference 2020

Thermo-hydraulic

J.-D. Wheeler1, M. Pautard2, T. Gilloux2, P. Namy1, C. Coulouarn2

1 SIMTEC, 38000 Grenoble, France

2 THALES

In order to optimize the industrial “ammunition cooling” process, a COMSOL Multiphysics® model is proposed. A shell body filled with a melt-cast explosive formulation is poured and cooled by circulation of a heat transfer fluid.

The solidification of the explosive composition has several thermal and fluidic consequences. To account for the solidification enthalpy, the “modified heat capacity” method is introduced to the model. Besides, the solid and liquid phases have very different densities. This results in convection within the liquid explosive composition part which requires solving the Navier-Stokes equations under their weakly compressible form. The free surface of the mixture varies thanks to a moving mesh, and the solid phase is modelled through a zero velocity in the Navier-Stokes equations.

The cooling process ensures a controlled loss of heat throughout the shell, from its bottom to its top. This allows for a continuous and unique solidification front. The top of the shell is maintained above the solidification temperature whereas the bottom of the device is cooled by pulsed air or water. Thanks to the simulation results, the industrial process has been optimized by reducing the cooling time and improving quality.

The app previously developed in 2017 has been improved to account for the physical phenomena which are introduced. COMSOL Server™ enables a remote computing to the users, thanks to an https secured internet connexion.

Lien pour recevoir l'article


Modelling of an Innovative Directional Ultrasonic Atherosclerosis Treatment Device

COMSOL European Conference 2020

JD.Wheeler1, V. Bruyere1, N. Aeby2

1 SIMTEC, 38000 Grenoble, France

2 Designer of the service

Pressure distributionat the tip vicinity and area of pressure (in teal colour) reaching the vapor pressure of water

Atherosclerosis prevalence keeps increasing worldwide because of the sedentary lifestyle and aging of the population. It is a pathology which is characterized by the build-up of plaque on the artery walls. While it has no incidence at the beginning, the blood flow can be severely altered in the most advanced cases. Atherosclerosis can lead to lethal consequences.

Several methods can be used to allow for a normal blood flow recovery; they are known as angioplasty. Whereas some of them rely on the flattening of the plaque, many atherosclerosis require to be properly removed. The removal can be made by different methods including ultrasonic waves.

The present article introduces a modelling of the latter method and focuses on the generation of the ultrasonic waves which produces cavitation. Whereas existing angioplasty ultrasonic devices producing cavitationhave a single degree of freedom and generate a cavitation field only in one direction, the present device is driven not by only one piezoelectric actuator but by three independent piezoelectric actuators (patented concept). Therefore, the generated cavitation field can be oriented and focused on specific areas of the artery wall and better target the plaque.

The model includes a coupling between the ultrasonic tip mechanical movement and the acoustical behaviour of the aqueous environment surrounding the tip. The acoustical field allows for a precise prediction of the cavitation generation and the Rayleigh-Plesset equation provides predictions of the bubble’s dynamic.

Thanks to the simulation results, a proof of concept was established and the directional abilities of the device have been optimised.

Lien pour recevoir l'article


Modeling of Charged Droplet Dynamics in an Electric Field using COMSOL Multiphysics®

COMSOL European Conference 2020

M.Sturma1, P.Namy2, V. Bruyère2 , B.Barbet1

1 MARKEM-IMAJE Industries

2 SIMTEC, 38000 Grenoble, France

Electric streamlines and Electric Field in the print head

In the field of coding and industrial marking areas, CIJ technology is based on high speed emission of ink drops (20 m/s) which are directed onto a moving printing medium.The printing quality depends, on one hand, on drops position on the media determined by thedrop charge and the electrostatic field, and on the other hand, on the position accuracy which depends on unwanted drops interaction in flight (electrostatic repulsion and aerodynamic effects). For instance, in a 24-points matrix, there are 2^24 combinations which cannot be predetermined experimentally. COMSOL Multiphysics enables to model these coupled effects in order to predict the location of a drops line on the medium, and this way, to create an aid to design CIJ printer heads. First, the 2D electrostatic field, defined mainly by the electrodes geometry, is computed thanks to the AC/DC module. Then, the particle tracing module is used to compute the droplet trajectory in the electrostatic field by modelling the droplet as a charged material point subjected to the Lorentz force and the Coulomb one. This electrostatic repulsion, describing the droplet-droplet electrostatic interaction, is taken into account thanks to the particle tracing module.This paper describes the coupled model which allow to compute droplets trajectory until the prediction of droplet positions on the printing media. Numerical results are compared to experimental data to validate the predictions quality and the model as a design support tool.

Lien pour recevoir l'article


Experimental and numerical simulation of pits on a corroded 316L grade stainless steel

COMSOL European Conference 2020

E.Sassine1, J.Rosec2, V.Bruyère1, R.Fargere2, P.Namy1

1 SIMTEC, 38000 Grenoble, France

2 Naval Group, Bouguenais, France

Numerical simulation results showing pH distribution and pit’s shape after 30 yearsCorrosion is an ongoing issue in metallurgic field. Stainless-steel products are likely to corrode in certain environmental conditions, especially if they are exposed to marine environment where localized corrosion can occur. The aim of this work is to study the behavior of 316L grade stainless steel subjected to pitting corrosion in a marine solution. The originality of this paper is that chemical kinetics parameters used in numerical simulation are based on experimental campaign in artificial seawater. Pitting initiation mechanism is not be treated in this paper and the main interest is focused on pits development. 2D Axisymmetric simulations in transient mode were accomplished thanks to COMSOL Multiphysics® software. The analysis of the experimental measurements indicates that mean width and depth of pits are relatively close, so pits can be considered as a hemisphere. Numerical results show that pit propagation depends on its initial form. A hemispherical pit keeps its shape during propagation (only its radius increases over time) while an ellipsoid pit has a different behavior.

Lien pour recevoir l'article


Optimizing your Femtosecond Laser Processes using a Numerical Simulation based Decision Support Tool

COMSOL European Conference 2020

E.Chevallier1, V.Bruyère1, G.Bernard2, P. Namy1

1. SIMTEC, 38000 Grenoble, France

2. GFMS, Meyrin, Switzerland

Physical phenomena involved in the ultrashort laser ablation

The use of ultrashort regime in laser ablation is increasing in industries as it allows better precision and reduces the heat affected zone of each impact. In this paper, a finite element model of the femtosecond laser matter interaction is presented. The aim of this model is to inform the laser user on the topography that will be obtained given the laser parameters selected, such as average power, pulse duration, frequency, etc. At these timescales, the classic temperature modelling approach cannot be used as the system is not at equilibrium. The two-temperature model is used to capture the heating of the electrons during the first period followed by the diffusion of the electron energy to the lattice. The model is calibrated against experimental topography data, width and depth of the crater, extracted from literature. A linear extrapolation to predict the depth, width and ablated volume of the crater is proposed and its validity within 10% is assessed for impacts created with up to 1000 pulses.

Lien pour recevoir l'article


Modeling of the Magnetic Field in a Vacuum Arc Remelting Furnace using COMSOL Multiphysics®

COMSOL European Conference 2020

V. Bruyère1, P.Namy1, I.Crassous2, F. Alex2, C. Deville-Cavellin2

1 SIMTEC, 38000 Grenoble, France

2 FRAMATOME, 73400 Ugine, France

 z-component of the non-dimensioned magnetic field

The vacuum arc remelting is a refining process used to melt reactive metals like titanium, zirconium or hafnium. Melting is performed under vacuum to avoid reactions between liquid metal and oxygen which could be a source of pollution. This process is particularly well suited to purify impurities at high temperature and to minimize the segregation. Therefore, the company Framatome used it to produce Zirconium alloys dedicated to nuclear fields and medical fields. The VAR process consists in applying a current intensity between a zirconium electrode and the mold intended to receive the melted metal. An electric arc occurring between these two electrodes enables the bottom of the zirconium electrode to melt and fill in the mold. The cooled mold is usually made of copper and equipped with coils to apply an electromagnetic stirring. The control of the process is essential to ensure quality through chemical composition and structural homogeneity. For this reason, Framatome and Simtec companies have developed the modeling of the magnetic field in a vacuum arc remelting furnace using COMSOL Multiphysics®. This model is especially used to check the capacity of the system to ensure a homogeneous magnetic field for different melt parameters of different products. The evolution of the calculated magnetic field is discussed for different current intensities and compared with experimental values. The good agreement between the calculated and experimental results allows to improve both the coils design and the control of the process.

Lien pour recevoir l'article


A User-Friendly COMSOL Multiphysics® Application to Design a Generic Induction Furnace

COMSOL European Conference 2020

O.Brun, J.-D.Wheeler, J.-M.Dedulle, V.Bruyère, P.Namy

3 D view of the induced power distribution in the melt

SIMTEC, 38000 Grenoble, France

Metallurgical process of metal melting requires tremendous amounts of energy. A modern way to optimise the power required is to use an induction furnace. Such furnaces are efficient but more challenging to design and to run than a conventional device.

In order to design an induction furnace and to optimize the charge melting, a COMSOL Multiphysics® application is developed. This application runs a furnace electromagnetic model. The inductor, supplied with an alternative electrical current, creates a variable induction field B. Due to this field, an induced current appears in the melt and in the crucible. Thus, the charge starts to heat up. The input current frequency, the inductor properties and the melt material have a huge impact both on the heat quality and the meshing refinement required by the simulation. This application provides a user-friendly interface to easily set up a furnace configuration. The whole model is fully adaptable to most configurations. From the inductor electric supply circuit to the geometrical air gap size between the inductor and the crucible, most parameters are available to the user within the interface. Then, the mesh adapts itself to consider the specific requirements of the magnetic simulation field. This remeshing step is computed in a completely transparent manner for the user.

Using a 2D axisymmetric formulation, configurations can be solved to quickly provide post processing results based on concrete industrial needs, such as the power distribution in the charge or the global efficiency of the equipment.

Lien pour recevoir l'article


Numerical Simulation of Electro-Thermo-Mechanical Phenomena During Resistance Sintering

COMSOL European Conference 2020

S.Bourdon1, P.Rogeon2, V.Bruyère3, P.Namy3, C.Durand1, S. Roure1

Temperature distribution and current density streamlines during the sintering process

1SCHNEIDER ELECTRIC, EYBENS, France

2Univ. Bretagne Sud, IRDL, LORIENT, France

3SIMTEC, 38000 Grenoble, France

Resistance-sintering can be used in a powder metallurgy process as the heating step toconsolidate a metallic compact previously obtained by pressing a powder-alloy. This fast-sintering process consolidates electrically conductive powders by simultaneous application ofpressure and electrical current. An electro-thermo-mechanical model has been developed tosimulate an industrial process involving silver-based electrical contacts composites. A transientnumerical approach is used to solve this strong coupled problem. Specific laws, establishedthanks to extensive experimental characterizations, are implemented to describe the physicalproperties evolutions and the mechanical behavior of the composites during sintering. Finally,the numerical model is able to predict the dimensions and properties of the final sintered part.

Lien pour recevoir l'article


From the laser parameters to the tribological properties with COMSOL Multiphysics®

COMSOL European Conference 2019

V.Bruyère¹, J-D.Wheeler¹, P.Namy¹

¹ SIMTEC, 38000 Grenoble, France

Tribological properties

In this work, the authors compare two different approaches to obtain the topography of laser texturation. Their aim is to demonstrate their strengths and weaknesses when being used as input data in a fluid lubrication model able to take into account non smooth surfaces. The first method consists in including the height distribution stemming from topography measurements. The second is rather different and deals with the numerical predictions of the topography. Indeed, SIMTEC has developed a thermo-hydraulic model to quantitatively predict the shape of the laser crater. The output of such a model is a prediction of the topography.

The lubrication results obtained with the numerical predictions are presented, together with the strengths and difficulties of both methods.

Lien pour recevoir l'article


Multi-scale modelling of a reacting flow through a porous bed using COMSOL Multiphysics®

Porous Bed

COMSOL European Conference 2019

S.Bouchex-Bellomie1, T.Paris1, V.Bruyère2, P.Namy2, J. M.Dedulle2

¹CEA Valduc, 21120 Is sur Tille, France

²SIMTEC, 38000 Grenoble, France

Using the software COMSOL Multiphysics based on the finite element method, a one-dimensionnal model has been developped to predict the transient behaviour of a gas flow through a porous bed. The problem is solved at a macroscopic scale, therefore, the porous bed is seen as a continuum with adapted equations such as Darcy’s law. Because the gas phase is composed of different species, diffusive effects are taken into account. The solid matrix is composed of a metal which can absorb gas within its lattice. Therefore, chemical exchanges occur between the gaseous species and the species initially loaded in the solid phase. The chemical exchange is assumed to be rate-limited by the surface exchange taking place at the gas and solid phases interface. Thermal effects are also taken into account and coupled with the others mechanisms (convection, diffusion and chemical reaction). Finally, numerical results have been compared with experimental data from the litterature.

Lien pour recevoir l'article


Femto-second laser texturing prediction using COMSOL Multiphysics®

Laser Femto

COMSOL European Conference 2019

E.Chevallier¹, V.Bruyère¹, G.Bernard², P.Namy¹

¹SIMTEC, 38000 Grenoble, France

²GFMS, Meyrin, Switzerland

Femto-second laser texturing offers the possibility to reduce significantly the amount of molten material. This means better surface properties as well as more accurate prediction of the surface topography. At SIMTEC, we developed a 2D time dependent model. The ultra-short deposition of the energy is taken into account in this model through an approach called the “two-temperature model”, which consists in modelling the Thermalization of the electrons followed by the energy transfer from the electrons to the lattice.

In this article, we review the range of pulse duration requiring the use of this two-temperature model. The results show that for pulses lower than several tens of picoseconds, the lattice and electron temperature are significantly different indicating the need to use the two-temperature model. This is in accordance with physical phenomena description of ultrashort laser impacts.

Lien pour recevoir l'article


When Precise Numerical Predictions Come to the Rescue of Liquid Lubrication

tribology

COMSOL European Conference 2018

J. D.Wheeler¹, V.Bruyere¹, P.Namy¹

1. SIMTEC, 38000 Grenoble, France

Whereas some bearings designed in the 19th century are still working properly nowadays, some more recent ones encountered premature failures. Tribological applications, such as journal bearings or rolling element bearings, are ruled by complicated multiphysical phenomena.

An appropriate numerical model is one of the most efficient mean to better understand the physics of these applications. Such a model involves the solving of the Reynolds equation. At high loads, solid deformations may also play a role. The contact would then follow an elasto-hydrodynamic behaviour. Moreover, the lubricant shearing is very likely to generate a significant heat which should be accounted for.

A simple tribological model, the lubricated pad, is presented in this article. Its goal is to address the different challenges that may be involved under different working conditions. A COMSOL application based on the model developed for this tribology case is also developed. It is run with COMSOL Server™.

Lien pour recevoir l'article


Free Surface Deformation of the Weld Pool in Orbital Narrow Gap GTA Welding

soudage

COMSOL European Conference 2018

S. Morville¹, V. Bruyère², P. Namy²

¹ Technical Center FRAMATOME, France

² SIMTEC, 38000 Grenoble, France

Arc current welding is a widespread process in heavy industry for the assembly of metallic components. In order to ensure the good quality of welded assemblies, it is appropriate to master the welding process but also to have a deep understanding of interactions with the weld pool and resulting characteristics. Numerical simulation is used as a predictivein situ analysis tool which provides additional data to real-time measurements. It involves taking into account heat transfer and fluid flow inside the melt pool, but also electromagnetic phenomena induced by the electrical arc. For that purpose, a 3D steady-state model is implemented with energy, momentum, mass and current conservation equations and by taking into account the deformation of the free surface with an ALE method. Marangoni effect, Lorentz forces and Buoyancy are also included. Results are in good agreement with the state-of-the-art knowledge.

Lien pour recevoir l'article


Finite Element Prediction of Laser-Material Interaction using COMSOL Multiphysics®

SHARK

COMSOL European Conference 2018

E.Chevallier¹, V.Bruyère¹, TianLong See², P.Namy¹

¹. SIMTEC, 38000 Grenoble, France

². Manufacturing Technology Centre (MTC), United Kingdom

Surface engineering is a key technology used in a wide range of sectors in industry. Among other techniques, it involves adding functionality to a surface. The objective of the work presented in this paper is to build an application using COMSOL Multiphysics® to predict the topography produced given the set of laser parameters as well as the material properties of the sample to be textured.

The application of the model is twofold. First, the influence of the laser parameters such as power, frequency and impact duration on the final topography is assessed. Then, an application is created using the Application Builder so the surface topography prediction can be integrated in a laser machine, enabling the future user to predict the topography of one laser impact on its sample, using COMSOL Server™. The topography is further used in the machine to predict the surface functionality of the sample (wettability, friction coefficient etc.).

Lien pour recevoir l'article


Influence of a Porous Corrosion Product Layer on the Corrosion Phenomenon of Carbon Steel Pipelines

corrosion

COMSOL US Conference 2018

M.Mohamed-Saïd¹, P.Namy¹

¹ SIMTEC, 38000 Grenoble, France

Assessing the severity of the internal corrosion of structures is of paramount importance in the oil & gas industry. Considerable effort has been deployed to implement an adequate electrochemical process of the corrosion phenomenon. However the influence of transport phenomenon trough a porous corrosion product layer (CPL) on the corrosion rate has not been studied extensively yet.

The transport phenomenon can influence the corrosion rate significantly by either limiting or accelerating the cathodic contribution. In this paper the general corrosion of a carbon steel under a porous CPL of siderite is studied and the influence of the transport phenomenon is examined using COMSOL Multiphysics ®. This model constitutes a first step and can be used for further development in order to assess the effect of either, a competitive diffusion trough a CPL or a conductive CPL, on the corrosion phenomenon.

Lien pour recevoir l'article


Adaptive Mesh Refinement: Quantitative Computation of a Rising Bubble using COMSOL Multiphysics®

maillageadaptatif

COMSOL European Conference 2018

T.Preney¹, P.Namy¹, J-D.Wheeler¹

1. SIMTEC, 38000 Grenoble, France

To accurately measure the variation of the unknowns, a relevant mesh should have a high density of degrees of freedom in regions where the norm of the gradient of the quantity of interest is significant. Fine meshes, on the other hand tend to induce long computational times, especially when complex 3D physics (fluid mechanics, electromagnetism …) are involved.  The Adaptive Mesh Refinement (AMR) method implemented in COMSOL Multiphysics® can help to mitigate computational time while maintaining precision. Instead of using a fixed mesh throughout the simulation, the initial mesh is adapted to the solution while the simulation is computed.

In this paper, the rising of a gas bubble in a liquid is modelled with the finite element (FE) software COMSOL Multiphysics® using a two-phase flow approach. Results from literature are compared with results obtained using both fixed and adaptive meshes. The results from the AMR method available in COMSOL Multiphysics® are then compared with results obtained with different software: NaSt3D and OpenFOAM.



Lien pour recevoir l'article


Manufacturing of Dysprosium-Iron Alloys by Electrolysis in Fluoride-Based Electrolytes. Electrolysis in a Laboratory-Scale Cell

Metall. Mater. Trans. 2018

electrolysis

A. M.Martinez1, K.S. Osen1, A.Støre1, H.Gudbrandsen1, O.S.Kjos1, A.Solheim1, Z.Wang1, A.Oury2, P.Namy2

1. SINTEF Industry, Sem Saelands vei 12, 7465 Trondheim, Norway

2. SIMTEC, 38000 Grenoble, France


Electrolytic production of light rare earth elements and rare earth alloys with transition elements takes place in a fluoride-based electrolyte using rare earth oxides as raw material. The optimization of this method, mainly in terms of the energy efficiency and environmental impact control, is rather challenging. Anode effects, evolution of fluorine-containing compounds and side cathode reactions could largely be minimized by good control of the amount of rare earth oxide species dissolved in the fluoride-based electrolyte and their dissolution rate. The Dy2O3 feed rate needed for stable cell operation was studied by following up the anode voltage and gas analysis. On-line analysis of the cell off-gases by FTIR showed that the electrochemical reaction for the formation of Dy-Fe alloy gives mainly CO gas and that CF4 is starting to evolve gradually at anode voltages of ca. 3.25 V. The limiting current density for the discharge of the oxide ions at the graphite anode was in the range of 0.1 to 0.18 A cm2 at dissolved Dy2O3 contents of ca. 1 wt pct. Modeling of the laboratory cell reactor was also carried out by implementing two models, i.e., an electrical model simulating the current density distribution at the electrodes and a laminal bubbly flow model that explains the electrolyte velocity induced by gas bubble production at the anode.

Lien pour recevoir l'article


Compressible Flow Modeling Occurring in a Depressurization Process

COMSOL European Conference 2017

pipe flow

V.Bruyère1, T.Paris2, F.Viry1, P.Namy1
1 SIMTEC, 38000 Grenoble, France
2 CEA DAM, Valduc, Is-sur-Tille, France


The depressurization process is the emptying of one tank to another one through a pipe network. In order to optimize the design of pipes and tanks, a good knowledge of the gas flow behavior is required. The modeling of compressible flows with a Mach number near 1 is quite challenging and simplifications are necessary to create an efficient numerical tool. Thus, a simple model is developed here, using COMSOL Multiphysics® and the “Non-Isothermal Pipe Flow” interface. A theoretical validation is made by confrontation with analytical results. Then, using experimental results in multiple configurations, the model is adjusted to make it predictive.

Lien pour recevoir l'article


Towards a Quantitative Prediction of Ice Forming at the Surface of Airport Runways

COMSOL European Conference 2017

piste aeroport

J. D.Wheeler1, M.Rosa2, L.Capobianco2, P.Namy1
1. SIMTEC, 38000 Grenoble, France
2. Groupe ADP - Laboratoire DIAMLX, 16 rue du Miroir, Roissy Charles de Gaulle, 95931, France


Anticipation of meteorological events such as ice forming is a key challenge to optimize the use of deicing/anti-icing products on airport runways. To obtain a predictive numerical tool of ice forming on the runways, Groupe ADP and SIMTEC developed a COMSOL Multiphysics® model, in which several physical phenomena contributing to the surface temperature variations of the runway are involved. Radiative exchanges occur from and to the atmosphere together with the solar radiations. Moreover, the underground thermal inertia has a key role as it varies depending on the season and the runway temperature of the previous days. At last, the wind is also a source of thermal variation because of the convection. A comparison with temperature measurement on the runway provides an evaluation of the model abilities. Whereas some phenomena contribution precision should be improved, the computation results are in agreement with the experimental measurements. Thanks to the numerical model, the different thermal contributions are gathered and the variation of the temperature is computed over time at the surface and in the different layers of the runway foundation.

Lien pour recevoir l'article


Optimization of an explosive mixture cooling process including a phase change

COMSOL European Conference 2017

Interface TDA

J. D.Wheeler1, C.Coulouarn2, E.Benade2, P.Namy1
1. SIMTEC, 38000 Grenoble, France
2. Thales TDA, Thales, La Ferté-Saint-Aubin, 45240, France


In the scope of improvement of the industrial “ammunition cooling” process, a COMSOL Multiphysics® model is developed to transfer an existing cooling process. A shell body is filled with a liquid explosive mixture. When all the shells have been filled the “cooling phase” takes place using specific equipment. This explosive mixture undergoes a phase change during the cooling and the solidification enthalpy is introduced to the model thanks to the “modified heat capacity” method. The specific equipment allows for cooling shells from its bottom to its top and therefore to ensure a continuous and unique solidification front. While the air surrounding the top of the device is heated, the bottom of the device is either soaked in water or cooled via a high velocity air flow. Thanks to the modelling approach, the industrial transfer had been optimized, by minimising set parameters for cooling phase. A user-interface is developed to allow the users of the model to easily vary the cooling conditions and the shell body geometry. COMSOL Server™ enables a remote computing to the users, thanks to an https secured internet connexion.

Lien pour recevoir l'article


Numerical modeling of flow focusing: Quantitative characterization of the flow regimes

Physics of Fluids 2017

aeropsray

V. Mamet1,2, P.Namy3, J.-M.Dedulle1,3
1 Laboratoire des Materiaux et du Genie Physique (LMGP), Grenoble INP–CNRS, 38016 Grenoble, France
2 DBV Technologies, 92220 Bagneux, France
3 SIMTEC, 38000 Grenoble, France



Among droplet generation technologies, the flow focusing technique is a major process due to its control, stability, and reproducibility. In this process, one fluid (the continuous phase) interacts with another one (the dispersed phase) to create small droplets. Experimental assays in the literature on gas-liquid flow focusing have shown that different jet regimes can be obtained depending on the operating conditions. However, the underlying physical phenomena remain unclear, especially mechanical interactions between the fluids and the oscillation phenomenon of the liquid. In this paper, based on published studies, a numerical diphasic model has been developed to take into consideration the mechanical interaction between phases, using the Cahn-Hilliard method to monitor the interface. Depending on the liquid/gas inputs and the geometrical parameters, various regimes can be obtained, from a steady state regime to an unsteady one with liquid oscillation. In the dispersed phase, the model enables us to compute   e evolution of fluid flow, both in space (size of the recirculation zone) and in time (period of oscillation). The transition between unsteady and stationary regimes is assessed in relation to liquid and gas dimensionless numbers, showing the existence of critical thresholds. This model successfully highlights, qualitatively and quantitatively, the influence of the geometry of the nozzle, in particular, its inner diameter.

Lien pour recevoir l'article


Modeling of the Lithium Hydride Hydrolysis under Low Relative Humidity

International Journal of Hydrogen Energy 2017

mécanisme réactionnels hydrolyse LiH

A.Oury2, P.Namy2, JP.Bellat3, E.Sciora3, R.Besnard1
1 CEA Valduc, 21120 Is sur Tille France
2 SIMTEC, 38000 Grenoble, France
3 Laboratoire Interdisciplinaire Carnot de Bourgogne, UMR 6303 CNRS, Universite Bourgogne Franche-Comte, 9 A. Savary, BP47870, 21078 Dijon, France



A reactional mechanism describing the hydrolysis of lithium hydride (LiH) under moist atmosphere is proposed and modeled. It involves the formation of lithium oxide (Li2O) at low vapor pressure and both lithium oxide and lithium hydroxide (LiOH) at higher vapor pressures, with diffusion of water in these layers. A numerical model based on this mechanism is implemented with COMSOL Multiphysics to simulate the hydrolysis of LiH particles in open system (constant water vapor pressure). Kinetic parameters such as rate constant of reactions and diffusion coefficient of water in Li2O and LiOH are first fitted against experimental data. The best agreements are obtained when the diffusion coefficient of water is 10 times higher in LiOH than in Li2O. The resulting model accurately predicts the hydrolysis rates experimentally measured for a wide range of water vapor pressures (0.3e17 Pa). The hydrolysis mechanisms are compatible with a Li2O production limited by water diffusion and a LiOH production governed by the kinetics. Finally, simulation suggest that the thickness of the Li2O layer does not depends much on the water vapor pressure whereas that of LiOH increases drastically at high water vapor pressures.

Lien pour recevoir l'article


Multiphysics Modeling of Pulsed Laser Welding

ICALEO 2016

Laser welding

V. Bruyère2,  C.Touvrey1, P.Namy2, N.Authier1
1CEA Valduc, 21120 Is sur Tille France
2SIMTEC, 38000 Grenoble, France


Laser beam welding is largely used in industrial manufacturing because of the advantages it provides, such as high-quality welds. Nevertheless, depending on the operating conditions, porosities or unwanted deformations can be produced during welding operations. In order to understand and control the responsible underlying mechanisms, numerical models are developed in a unique finite element formalism. All models are based on experimental characterizations. First of all, a thermal-hydraulic model is developed to predict the dimensions of the melted zones and the heataffected zones as well as the mechanisms of porosities formation for a Ti6VAl4 alloy. A thermal-mechanical model including metallurgical phase changes is then developed in order to predict the residual states of stress and strain. The heat source is calibrated with an optimization procedure based on thermal-hydraulic analysis. Indeed, an equivalent approach is used to reduce the computational time for thermal-mechanical computations. Finally, this model is applied to a study case and numerical results are discussed and compared with experimental data.

Lien pour recevoir l'article


Implementation of an Interferometric Sensor for Measuring the Depth of a Capillary Laser Welding

ICALEO 2016

Interferometric Sensor

N.Authier1, A.Baptiste1, C.Touvrey1, V.Bruyere2,  P.Namy2
1CEA Valduc, 21120 Is sur Tille France
2SIMTEC, 38000 Grenoble, France


The welding laboratory located at the Commissariat a l'Energie Atomique et Aux Energies Alternatives (CEA) Valduc center in France uses pulsed and continuous wave (CW) laser sources to assemble metallic parts of low thicknesses. This article discusses the results obtained by the recent implementation of the In-process Depth Meter (IDM) of PRECITEC keyhole depth measurement sensor in our laboratory. This distance measurement technology uses a Michelson interferometer adapted to the very special conditions of the laser beam welding. Micrographs of pulsed welding tests on 316L stainless steel, TA6V plane sheets butt joints are analyzed and compared to the inline collected signals. The system's ability to follow dynamically the formation of the keyhole into the molten metal is evaluated and compared to numerical models performed in the lab using the nite element COMSOL Multiphysics software.

Lien pour recevoir l'article


Electrical and Bubbly Flow Modeling of a Molten Salt Electrolysis Cell

COMSOL European Conference 2016

Molten Salt Electrolysis

A.Oury1, P.Namy1, A.M.Martinez2, K.S. Osen2, A.Solheim2
1SIMTEC, 38000 Grenoble, France
2SINTEF Materials and Chemistry, Sem Saelands vei 12, 7465 TRONDHEIM, Norway

A laboratory-scale electrolysis cell for the recovery of metals is simulated with COMSOL Multiphysics. Two models are implemented: an electrical model simulating the current density (reaction rate) distribution at the electrodes and a laminar bubbly flow model which solves for the electrolyte velocity induced by gas bubble production at the anode. A parametric study on the mesh refinement, the anode-cathode distance (ACD) as well as the bubble diameter (Db) is carried out. Quite heterogeneous current distributions are simulated at the electrodes’ surface, with strong edge effect at the cathode. At the anode, a more uniform current is however obtained when increasing ACD. The bubbly flow model suggests that significant electrolyte convective motions between the electrodes are favoured for small values of both ACD and Db.

Lien pour recevoir l'article


Aerothermal Simulation of a Refrigerated Truck Under Open/Closed-Door Cycles

COMSOL European Conference 2015

airtruck

A.Oury1, P.Namy1, M.Youbi-Idrissi2
1 SIMTEC, 38000 Grenoble, France
2 AIR LIQUIDE, Jouy en Josas, France

Heat transfer inside a refrigerated truck is a key phenomenon that governs the temperature inside the truck and the regulation of the cooling system. Up to now, a lot of experimental studies ([Tso et al., 02]) have been carried out to assess the effect of opening the door and to minimize the external heat transfer with fan air curtain. Together with AIR LIQUIDE, the world leader in gases, technologies and services for Industry and Health, SIMTEC, a French COMSOL certified consultant company, has developed a numerical model in COMSOL Multiphysics® software to simulate the heat transfer phenomena occurring during the use of the refrigerated truck, considering both open- and closed-door periods. The model is based on a coupling between CFD (k-ε/k-ω models) and heat transfer. Comparison with experimental results shows a reasonable agreement in terms of temperature inside the volume and at some specified points. This work demonstrates the feasibility of using COMSOL to model non-isothermal turbulent flow.

Lien pour recevoir l'article


Numerical Characterizations of Viscoplastic Behavior of TA6V with Metallurgical Phase Change

COMSOL European Conference 2015

evolutionphase

V.Bruyère2, C.Touvrey1, P.Namy2
1 CEA Valduc, 21120 Is sur Tille
2 SIMTEC, 38000 Grenoble, France

In order to predict the residual mechanical state of assemblies during pulsed laser welding, mechanical and metallurgical behaviors of the materials need to be precisely characterized. Based on experimental data and analyses, a numerical model is developed in Comsol Multiphysics to take into account the predominant effects (metallurgy influence, viscoplastic behavior) identified for TA6V. To validate our implementation, experimental and numerical results are compared at different temperatures.

Lien pour recevoir l'article


A Phase Field Approach to Model Laser Power Control in Spot Laser Welding

COMSOL European Conference 2014

comparaison expérience/numérique

V.Bruyère2, C.Touvrey1, P.Namy2
1 CEA Valduc, 21120 Is sur Tille
2 SIMTEC, 38000 Grenoble, France

Spot laser welding is largely used in industrial manufacturing, especially in the case of small penetration depth. Unfortunately, welded joins are often polluted by porosities. The formation of porosities depends on complex thermo-hydraulic phenomena. To understand and control these mechanisms, the COMSOL Multiphysics software is used to model both the interaction and cooling stages of an isolated impact made with a Nd:YAG pulsed laser. The model is based on the Phase Field method in order to apprehend the evolution of the liquid-gas interface shape. The numerical results are compared to experimental characterizations for different operating conditions. At last, the benefic effect of the laser power control (pulse shaping) is demonstrated.

Lien pour recevoir l'article


Thermohydraulic modeling of pulsed laser welding

ICALEO 2013

laser welding

V.Bruyère2, C.Touvrey1, P.Namy2
1 CEA Valduc, 21120 Is sur Tille
2 SIMTEC, 38000 Grenoble, France

The major aim of this study is to increase our understanding of the link between operating parameters and thermo-hydraulic evolution in the welding area, in the case of an isolated impact made with a Nd:YAG pulsed laser on a thin Ti6Al4V sheet. Two numerical approaches are used to model both the interaction stage and the cooling one. During the interaction, the free surface behavior is precisely described by a moving mesh method (ALE method). The dependence between the interface temperature and the recoil pressure is discussed and a simplified approach is used. The keyhole collapse and the cooling stage are modeled by the phase field method (Eulerian method), which enables to consider the behavior of the gas trapped into the melting pool. Numerical calculations are compared to experimental characterizations (melted zone shape and defects position), in the case of relatively low laser power (inferior to 1000 W).

Lien pour recevoir l'article


Comparison between Phase Field and ALE Methods to model the Keyhole Digging during Spot Laser Welding

COMSOL European Conference 2013

laser welding

V.Bruyère1, C.Touvrey1, P.Namy2

1 CEA Valduc, 21120 Is sur Tille
2 SIMTEC, 38000 Grenoble, France

Nowadays, spot laser welding is a full-fledged part of industrial manufacturing and is routinely used due to its advantages. It generates very located temperature gradients, and therefore, induces small distortions in the pieces. The COMSOL Multiphysics software is used to model the interaction stage of an isolated impact made with a Nd:YAG pulsed laser. The free surface evolution has been precisely described with a moving mesh method (ALE method) by imposing the recoil pressure and the energy deposition as boundary conditions. The results have been compared with those obtained with a fixed mesh method (Phase Field method) for isothermal and thermal cases. A discussion is proposed to choose the more appropriate method to model this problem.

Keywords: Welding, ND : YAG pulsed laser, Thermo-hydraulic, ALE, Phase-Field method.

Lien pour recevoir l'article


Modélisation de la formation des défauts de type porosité lors du soudage de matériaux métalliques par laser impulsionnel

Séminaire CNRS Européen Recherche/Industrie Laserap'7

laser welding

C.Touvrey1, P.Namy2, C.Cossu1
1 CEA Valduc, 21120 Is sur Tille
2 SIMTEC, 38000 Grenoble, France

Le procédé de soudage par laser impulsionnel permet d'assembler des pièces métalliques par une succession d’impacts, produisant chacun une fusion localisée de la matière. À la fin de l’impact laser, les phases de remplissage du capillaire et de solidification du métal liquide se succèdent. Des bulles de gaz emprisonnées dans le bain de soudage peuvent alors conduire à la formation de porosités. Afin d’améliorer notre compréhension du lien entre les propriétés thermophysiques des métaux et les risques de formation des défauts, un modèle numérique reliant les caractéristiques géométriques du bain fondu et la durée de remontée des bulles de gaz a été élaboré au sein du code COMSOL. Ce modèle se borne à représenter les phénomènes physiques après l’arrêt du faisceau laser, une fois le capillaire de soudage rempli. Le calcul prend en compte la remontée des bulles sous l’effet de la poussée d’Archimède, l’influence de la tension de surface, et l’avancée du front de solidification liée au refroidissement (calcul thermohydraulique couplé). Des calculs ont été menés pour deux matériaux, le tantale et l’alliage de titane TA6V, pour différentes tailles initiales de bulles.

Lien pour recevoir l'article


Formation of Porosities During Spot Laser Welding of Tantalum

COMSOL European Conference 2011

laser welding

C.Touvrey1, P.Namy2
1 CEA Valduc, Is-sur-Tille, France
2 SIMTEC, 38000 Grenoble, France

The aim of the study is to predict the formation of porosities in the case of spot laser welding of tantalum. During the interaction, a deep and narrow cavity, called the keyhole, is generated. At the end of the interaction, surface tension provokes the collapse of the keyhole. Gas bubble can then be trapped into the melting pool, and give birth to residual porosities, according to the solidification time.

A model has yet been developed to simulate keyhole collapse. This model was presented at the last COMSOL European conference. The purpose of the present study is to simulate the bubble up rise. The problem is especially complex due to the high surface tension of the liquid tantalum (2.1 N.m-1).

Lien pour recevoir l'article


Comparison Between Honeycomb and Fin Heat Exchangers

COMSOL European Conference 2011

honeycombP.Gateau1, P.Namy2, N.Huc3
1 SAS SYNGAS, Saint Viaud, France
2 SIMTEC, 38000 Grenoble, France

3 COMSOL, Grenoble, France

Metal honeycombs are used as catalyst supports. They can be considered as complex fins for heat exchange. A simple heat transfer model was compared with 2D simulations using COMSOL Multiphysics. There was a good correlation when the fluid temperature was the same in all cells. However, significant discrepancy apperared when compared with a 3D simulation with laminar flow.

Honeycomb cells produced a temperature gradient which reduced the heat transfer. The radiant transfer was also investigated using 2D simulation. Modeling using COMSOL revealed the drawbacks of using honeycombs in steam reforming reactors. 3D modeling showed that a careful representation of the inlet was needed for realistic results.

Lien pour recevoir l'article


Finite Element Analysis of Cables Heating Due to PoE/PoE+

COMSOL European Conference 2010

Temperature distribution within a cable bundle used to consider realistic geometries of the bundle .S.Francois1, P. Namy2
1Nexans Research Center, Lyon cedex, France
2SIMTEC, 38000 Grenoble, France

Power over Ethernet (PoE/PoE+) is a technology allowing to transmit data and power over the same data cable. The major concern for this technology is the degradation of data transmission performances due to the temperature increase in the cable. To have a better quantitative and qualitative knowledge of the temperature field in the cables, Nexans has developed a 2D finite element thermal model thanks the software COMSOL Multiphysics. In this model, the heat source is due to the joule effect, depending on the intensity level. This thermal model enables us to take into consideration several configurations of cable bundles and to optimize the temperature field thanks to cable design.

Lien pour recevoir l'article


Level Set Method for Fully Thermal-Mechanical Coupled Simulations of Filling in Injection and Micro-Injection Molding Process

COMSOL European Conference 2009

Vortices in the air domain.M.Moguedet1, R.Le Goff1, P.Namy2, Y.Béreaux3
1Pôle Européen de Plasturgie, Bellignat, France
2SIMTEC, 38000 Grenoble, France
3INSA de Lyon, Site de Plasturgie, Bellignat, France


In this work we tackle a more theoretical aspect of micro-injection molding, to better understand physics during the process, through numerical simulations of cavity filling. We developed a two phase flow approach by the use of COMSOL Multiphysics®. In a first step, a Level Set model is applied to several configurations: Newtonian and non Newtonian fluid (Cross viscosity law), coupled with a thermal equation and a thermal dependence of the viscosity (Williams-Landel-Ferry law). We take into account the unsteady thermal behavior of the mould while injecting the polymer into the cavity. Finally, as air –trapping often occurs in the injection molding process, we present some results considering a pseudocompression law (low Mach number) for the air. To conclude, we show the ability of the COMSOL model to simulate polymer filling in microfeatures.

Lien pour recevoir l'article


On the Use of COMSOL Multiphysics to Understand and Optimize the Filling Phase in the Injection and Micro-Injection Molding Process

COMSOL European Conference 2007

Newtonian front profile at t=0.01 s

M.Moguedet1, P.Namy2, Y.Béreaux3
1Pôle Européen de Plasturgie, Bellignat, France
2SIMTEC, 38000 Grenoble, France
3
LAMCOS, Site de Plasturgie, INSA Lyon, Bellignat, France

The work presented here deals with the simulation of the cavity filling stage of the injection and micro-injection molding process for thermoplastic materials. COMSOL Multiphysics gives us the means to take into consideration some other aspects usually neglected in commercial 3D softwares dedicated to polymer processing. In particular, tracking of the flow front is based on a Level Set approach. Results are presented for a Newtonian and non-Newtonian polymer, and in an isothermal or thermal dependant configuration. The calculations are compared to experimental results on a polypropylene.

Lien pour recevoir l'article


Convective Movements in an Electrolyser

COMSOL European Conference 2007

Convective Movements in an ElectrolyserB.Morel1, P.Namy2, C.Belhomme1, I.Crassous3
1Comurhex, Pierrelatte, France
2SIMTEC, 38000 Grenoble, France
3LI2C, Paris, France

Modeling electrolysers is a challenge because of the strong coupling between electrical, thermal and CFD equations. Indeed the electrical conductivity of the electrolyte varies with the temperature, which in turn depends on the heat dissipated by the Joule effect and anode over-voltage.In the present study, the fluid velocity values are computed near the electrodes using a diphasic level set model, but the full calculations are performed using a monophasic model. Our goal is to evaluate the relationship between the average temperature of the cell and the average current for a given cooling surface.

Lien pour recevoir l'article
